OVERVIEW
BULLETBLOCK bulletproof glass-clad polycarbonate products can also be used in interior applications but they are better suited for exterior applications where the glass outer layer provides a better protection against weathering and cleaning. Because these products contain glass they must be manufactured to size and cannot be stocked but the benefit of “made to size” is no yield loss from stock sheets. Also, because of their glass makeup, many of these products can be insulated providing much better thermal performance for exterior applications.
Whatever your security project needs you can be confident Insulgard has a glazing solution that will work for you. You can also be confident that the product you choose will perform when called upon. All of Insulgard’s
Our bulletproof glazing materials are tested and certified to UL752 by the Underwriters Laboratory and listed as such.
For more information about our bulletproof glass-clad polycarbonate glazing products read our product data sheets below or reach out to speak with one of our experts.
PRODUCTS
BALULN21
RATING: UL 752 Level 1
MATERIAL: Glass-clad polycarbonate glazing
NOMINAL THICKNESS: 0.860 In
WEIGHT: 9 lbs/sq ft
ARMOR-GARD® BALULN21-IG
RATING: UL 752 – Level 1 – UL Listed BP844
MATERIAL: Insulated glass-clad polycarbonate glazing
NOMINAL THICKNESS: 1.587″
WEIGHT: 10.35 lbs per SF
PERFORMANCE:
- 3 shots 9mm Luger, 124-grain FMJ, shot spacing @ 4.00″ triangle
- No Spall, No Penetration
APPLICABLE STANDARDS:
- ASTM C 1036-06
- ASTM C 1349-04
- UL752
- CPSC 16 CFR 1201 (Category I and II)
BALULN23
RATING: UL 752 Level 2
MATERIAL: Glass-clad polycarbonate glazing
NOMINAL THICKNESS: 0.960 In
WEIGHT: 10.34 lbs/sq ft
ARMOR-GARD® BALULN23-IG
RATING: UL 752 – Level 2 – UL Listed BP844
MATERIAL: Insulated glass-clad polycarbonate glazing
NOMINAL THICKNESS: 1.587″ In
WEIGHT: 10.35 lbs per SF lbs/sq ft
PERFORMANCE:
- 3 shots .357 Magnum Jacketed
- Lead Soft Point
- No Spall, No Penetration
APPLICABLE STANDARDS:
- ASTM C 1036-06
- ASTM C 1349-04
- UL 752
- CPSC 16 CFR 1201 (Category I and II)
ARMOR-GARD® SP412
RATING: UL 752 – Level 4 – UL Listed – File BP844
MATERIAL: Glass-clad polycarbonate glazing
NOMINAL THICKNESS: 1.22″ In
WEIGHT: 14.5 lbs per SF lbs/sq ft
PERFORMANCE:
- .30 Caliber Rifle Lead Core Soft Point (.30-06 Caliber)
- No Spall, No Penetration
APPLICABLE STANDARDS:
- ANSI Z97.1
- CPSC 16 CFR 1201 (Category I and II)
- ASTM C 1036
- ASTM C 1349
ARMOR-GARD® SP412-IG
RATING: UL 752 – Level 4 – UL Listed – File BP844
MATERIAL: Insulated glass-clad polycarbonate glazing
NOMINAL THICKNESS: 1.954″ In
WEIGHT: 17.719 lbs per SF lbs/sq ft
PERFORMANCE:
- .30 Caliber Rifle Lead Core Soft Point (.30-06 Caliber)
- No Spall, No Penetration
APPLICABLE STANDARDS:
- ANSI Z97.1
- CPSC 16 CFR 1201 (Category I and II)
- ASTM C 1036
- ASTM C 1349
BALULN25 IG
RATING: UL 752 Level 3
MATERIAL: Glass-clad polycarbonate
NOMINAL THICKNESS: 1.716 In
WEIGHT: 14.57 lbs/sq ft
BALULN25
RATING: UL 752 Level 3
MATERIAL: Glass-clad polycarbonate
NOMINAL THICKNESS: 0.980 In
WEIGHT: 11.3 lbs/sq ft
BALULN32
RATING: UL 752 Level 5
MATERIAL: Glass-clad polycarbonate
NOMINAL THICKNESS: 1.280 In
WEIGHT: 14.4 lbs/sq ft
BALULN32 IG
RATING: UL 752 Level 5
MATERIAL: Glass-clad polycarbonate
NOMINAL THICKNESS: 2.010 In
WEIGHT: 17.67 lbs/sq ft
BALULN50
RATING: UL 752 Level 7
MATERIAL: Glass-clad polycarbonate
NOMINAL THICKNESS: 1.930 In
WEIGHT: 22.22 lbs/sq ft
ARMOR-GARD® SP820
RATING: UL 752 Level 8
MATERIAL: Glass-clad polycarbonate
NOMINAL THICKNESS: 2.072 In
WEIGHT: 22.34 lbs/sq ft
PERFORMANCE:
- 5 shots .7.62mm Rifle Lead Core Full Metal
- Copper Jacket Military Ball (.308 Caliber)
- Tested at NTS-Chesapeake Testing following UL 752 Level 8
requirements - No Spall, No Penetration
APPLICABLE STANDARDS:
- ASTM C 1036
- ASTM C 1048
- ASTM C 1349
